Uniview Video Surveillance IP Fisheye Cameras | IPC814SR-DVSPF16

IPC814SR-DVSPF16

Discount group: 00 SKU: 4056843009065

Version:

Version
Material number
500906
Type
360° Panorama IP-Kamera
Max. Image resolution [pixels]
4 MP (2560x1440)
Edge recording
Lokal auf dem PC, FTP
Imaging sensor
1/3" Progressive Scan CMOS
Light sensitivity [lux]
0 (IR an)
Aperture
F1.6
Video codec
(U-)H.265,(U-) H.264, MJPEG
Viewing angle (horizontal)
180°
Shutter
1/6 - 1/100000
Aperture control
automaticallymanual
Max. Frame rate
25 fps@4MP
Title overlay
Ja
Bitrate per channel
H.265/H.265: 128-16384Kbps
Lens Focal length
1,6mm
D-O-R-I max.
36m - 14m - 7m - 4m
I/O switching contacts
1 / 1 FET Open Source max. 12VDC/0,1A; 1,2W
Audio inputs/outputs
1x Input: 35 kOhm/2Vss ; 1x Output: 600 Ohm/2Vss
Ethernet port
RJ-45
Ethernet standards
10Base-TX/100Base-TX
PoE Standard
IEEE802.3af
Max. Power consumption (watts)
11
ePoE / Long-Range PoE
Ja, bis 250m (mit UNV- Rekorder oder -IP-Switch )
Long Range PoE
Ja, bis 250m (mit UNV- Rekorder oder -IP-Switch )
Maximum cable length
typisch: max. 100m
Spotlight range [m]
10
LED wavelength
850 nm (IR)
Headlight range
10
Noise reduction
2DNR3DNR
Private zones
Ja, 8
Region of Interest (ROI)
8 Zonen
Backlight compensation
120dB TrueWDRBLC
Safety functions
HTTPS, SSL, IP Filter
Alarm management
HTTP, FTP, ONVIF
Translation missing: en.technical_info_table.products.unterstützebrowser
Internet Explorer 11
Camera setting
Webinterface, CGI, App, VMS
CCTV video output
BNC, 75 Ohm 1 Vss
Communication method
Unicast / Multicast / RTSP
Number of video streams
3 (einzeln konfigurierbar)
ONVIF
Profile S, Profile G
Supported software
EZStation und weitere
Supported protocols
HTTP,HTTPS,FTP,TCP,UDP, DHCP, SSH,NTP,ONVIF...
Supported software
ONVIF, API
P2P support
No (EZCloud)
smartphone app
EZView
Mounting type
Wand- und Deckenmontage
Protection classes
IP 66IK 10
Operating voltage
12 VDC (+/-25%), PoE
Operating temperature
-40 bis +60
SD card slot
Ja, max. 128GB (optional)
Active image elements
2688(H) x 1520(V)
White balance
Auto; Manual and more
Audio codec
G.711a / G711u
Max. Number of users
32
Signal/Noise ratio
55dB
Housing colour
Weiß
Dimensions diameter [mm]
125 x 43,7
Weight
0,39 Kg
Storage temperature
0 bis +50
Relative humidity
Bis 95, nicht kondensierend
Lieferumfang
Montagezubehör, RJ-45 Verschluss
Note
Uniview Software, z.B. um die Geräte im Netzwerk zu suchen, finden Sie unter Software bzw. Downloads&Software.
Marking
CE

Accessories and spare parts

40568438210494056843821049
TR-A01-IN
